• Fully passive in-line connection with PoE passthrough ensures fail-safe network access and operation
• Compact and portable form factor (69 x 124 x 24 mm) enables rapid deployment anywhere
• USB powered with flexible options for 5 VDC input when needed
• Hardware timestamping with 8 nanosecond resolution for accurate performance metric analysis
• Captures complete full-duplex 10/100 Mbps traffic without any packet loss
• Non-intrusive monitoring that remains invisible to the network as a node
• Monitors all 7 OSI layers for comprehensive network visibility
• Multiple capture methods including direct to disk, live with Wireshark, or long-term to NAS

• Portable design enables deployment in diverse network environments for quick troubleshooting
• Physical isolation between monitored network and management interface prevents injection and MITM attacks
• Compatible with major protocol analysers including Wireshark, CloudShark, ClearSight, OmniPeek, and others
• Packet slicing capability optimises disk storage and analysis workflow by capturing actionable data only
• Long-term traffic capture solution integrates with NAS for catching intermittent problems
• Flexible powering options support USB 3.0 port or 5 VDC input connector
• Cross-platform support for Windows, Linux, and macOS operating systems
• RoHS and CE certified with EN 45545-2 compliance for industrial applications


• Monitoring Capacity: 10/100 Mbps monitoring on USB
• Connectors: 2 x RJ45 8-pin, 1 x USB 3.0, 1 x 5 VDC optional input
• Timestamp Resolution: 8 ns hardware timestamp at ingress
• Dimensions: 69 x 124 x 24 mm (2.72 x 4.88 x 0.94 inches)
• Power Supply: USB powered or 5 VDC input
• PoE Support: 802.3af, VoIP, and PoE passthrough
• System Requirements: Dual Core Processor, 4 GB memory, USB 3.0 port
• Supported Operating Systems: Windows 7/8/10/11, Linux, macOS
• Included Accessories: 1.8m USB 3.0 cable, RJ45 cable, protective pouch, USB key
• Certifications: RoHS, CE, EN 45545-2 compliant

Datasheet – Download
