• Available with the Field Replaceable Optical Connector Protector System (US Patent 12,481,111) to improve durability and reduce downtime.
• Optical Time Domain Reflectometer (OTDR).
• Supports single-mode operation across 1310, 1550, 1625, and 1650 nm wavelengths.
• In-service testing enabled via filtered 1625 or 1650 nm port.
• Resolution of 3 cm with up to 500,000 sampling points.
• Live fibre detection helps prevent accidental service interruption.
• Dynamic range performance up to 50 dB.
• Typical event dead zone of 0.85 m and attenuation dead zone of 3.5 m.
• Advanced link mapping with optional V-Scout multi-pulse profiling.
• Optional integrated launch fibre for improved measurement accuracy.
• Fixed or universal connectors available with UPC or APC polishing.

Optical Power Meter (OPM)

• Supports multiple calibrated wavelengths.
• High-precision InGaAs detector for standard and high-power measurements.
• Measures absolute power (dBm, watts) and relative power (dB).
• WaveID detection for identifying incoming wavelengths from compatible VeEX light sources.
• Compatible with industry-standard optical adaptors.

Optical Light Source (OLS)

• Optional OLS functionality using the built-in OTDR laser.
• Stabilised output for insertion loss testing.
• WaveID and loop modes for multi-wavelength testing.
• Supports CW and modulation modes for fibre identification.
• Automatic power-off feature for improved battery efficiency.

Visual Fault Locator (VFL)

• Visible laser for fast fault detection and patch panel troubleshooting.
• Supports continuous wave (CW) and 1 Hz pulse modes.

MTTplus- 410+ Data sheet – Download

OTDR Series User Manual – Download
