• Rugged and lightweight design built for demanding field conditions
• 7-inch high-resolution colour touchscreen with intuitive graphical interface
• Ethernet LAN management port for remote access, back-office integration, and workforce management
• Fast data transfer via USB memory, FTP over LAN, or DOCSIS interfaces
• ReVeal™ PC software for configuration management, firmware updates, result processing, and report generation
• Interchangeable Li-ion battery packs for extended field operation
• Interface lock feature to prevent unintended changes during long-term testing
• Optional Wi-Fi Wiz with SSID analysis (InSSIDer)
• Optional Wi-Fi spectrum analyser
• Optional VoIP and IPTV testing tools
• Optional digital fibre inspection scope
• Optional optical power meter

• Frequency range from 5 MHz to 1 GHz
• Full SLM measurements, including single channel, system scan, tilt, and installation checks
• Video and audio power level measurements for Annex A, B, and C signals
• Forward and return path QAM analysis with MER, BER, constellation, histogram, and equaliser functions
• Advanced digital measurements, including HUM, EVM, phase jitter, symbol rate error, frequency response, and group delay
• DOCSIS 3.0 cable modem supporting up to 32×8 channel bonding
• Optional DOCSIS 3.1 cable modem support
• Patented subcarrier scan for interference detection
• Spectrum view for identifying impulse noise and signal interference
• Home Installation Procedure (HIP) with configurable test limits
• Optional upstream signal generator supporting CW, QPSK, and QAM modulation formats
• Ethernet testing up to 10 GigE with SLA validation (BERT, throughput, RFC2544, Y.1564 SAM)
• Built-in TDR support for up to 2 km (6000 ft) of coaxial cable
• Single DS1 transmitter/receiver with balanced 100Ω interface for full and fractional DS1 testing
• Optional ISDN PRI call setup
